A3 480GB 2.5 Inch SATA SSD Solid State Drive Disk 3D NAND 6GB/S Internal Solid S

Place of Origin: China
Brand Name: Zheino
Certification: CE RoHS FCC
Model Number: CHN-25SATA3-480
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: 155*110*16 mm
Delivery Time: 5-8 work days
Payment Terms:



Capacity: 480GB Controller: SM2258XT
Read Speed: 540MB/S Write Speed: 490MB/S
Size: 2.5" Nand Flash Type: 3D Nand
Application: Desktop,Laptop Package: Yes

A3 480GB 2.5 Inch SATA SSD Solid State Drive Disk 3D NAND 6GB/S Internal Solid State Disk

  • Capacity: 480GB, Interface: 2.5 inch SATAIII
  • Dimension: 3.93in X 2.76in X 0.28in / 100mm X 70mm X 7mm
  • NAND Flash:3D Nand; Controller: SMI2258XT
  • Read/write speed: 540MB/s, 490MB/s
  • Warranty: 3 Years


Capacity 480GB
Size 2.5 inch
Interface Type SATAIII
Model Number CHN-25SATA3-480
Controller SMI2258XT
Read Speed 540MB/s
Write Speed 490MB/s
4KB Random Read IOPS 5091
4KB Random Write IOPS 37711
input Voltage 5V
Idle 0.79
Active 1.71
Write Endurance 3000 P/E cycles
Read Endurance --
Data Retention More than ten years
MTBF 3 million hours
ECC Hardware BCH ECC capable of correcting errors up to 72-bit/1KB
Working Temperature 0~70
Storage Temperature -40~85

A3 480GB 2.5 Inch SATA SSD Solid State Drive Disk 3D NAND 6GB/S Internal Solid State Disk


1. Q: What are the advantages and disadvantages between solid-state drives and mechanical drives?

Compared with mechanical plat. SSD’s stability, shock resistance and high speed is an absolute advantage, SSD is not afraid throw and not afraid of earthquakes, the speed than traditional mechanical plate is faster at least three times, it’s suit to be system disk and running disk with large software. Its disadvantage lies in the capacity,the high capacity SSD’s price is high at present, but it does not affect the customers to use, for now as the price of 64g to 128g is quite cheap. Customers can use the SSD and mechanical disk storage state at the same time, solid state drives is used in systems and procedures, machinery is used in storing data.

2. Q: My computer is old version, wether I can use SSD? Will performance be promotion?

SSD is standard SATA interface,so if the computer could support the SATA interface,it could be installed and used,if the interface is above SATA2,the performance of the machine will have obvious ascension than the original general machinery plate.

3. Q:What’s the key points with destop computers installed SSD? Will it affect the speed?

SSD’s specifictions is 2.5inch,when it is used in desktop. Commonly it need to use the 2.5 turn 3.5inch stents as installing a desktop hard drive in the chasis. Its speed will not be affected, just like changing the main drive.

4. Q:Can’t find the SSD drive, can’t read and write data?

NEW SSD require be formatted to write and read data,it is recommended to use NTFS format under the windows operating system.

5. Q; What’s the difference between a ASTA2 interface and SATA3 interface?

The different between SATA2 and SATA3 is a new identification of interface transmission,is not different interface specification. Two kinds of interface compatible with each other.

6. Q:Warm tips

Any storage products don’t guarantee data security, please back up your data in time,we ae not responsible for loss of data.
